Displays



  An LED bar graph display.
  The display consists of 10 LEDs arranged side by side.





A seven segment LED display.




  A fluorescent display.
  Note the three thin wire heaters (cathodes) running
  along the length of the display.




A LED matrix display.





  A small Cathode Ray Tube form a portable TV
  from the 1970s. The deflection coils have been
  removed from the neck of the tube.




A dual beam oscilloscope tube (1970s).




  The deflection plates from a dual beam scope tube.




A dual beam oscilloscope tube (1970s).




  The Mu metal shield a dual beam scope tube.




The pixel pattern from a high resolution CRT monitor.





  The pixel pattern from a 26" CRT television.




The miniature CRT monitor from an early video camera.




  The scanning coils from a miniature CRT.




Laptop LCD screen.
The image is turned through 90°




  The inside of a small colour television.




The inside of a small colour television.




  Oil magnifier from early black and white television (C1950).
